Mingri Electric
1 / 3
| 1 | Three-phase Transformer |
| 2 | Resin Cast |
| 3 | Insulated Winding |
| 4 | Performance Level Code |
| 5 | Rated Capacity (kVA) |
| 6 | Voltage Class (kV) |
| Model | Empty loss (W) | Load loss (120℃) (W) | Short-circuit Impedance | Current (%) | Sound (dB) | Weight (kg) | Dimensions (mm) | |||
|---|---|---|---|---|---|---|---|---|---|---|
| a | b | c | h | |||||||
| SC(B)11-30/35 | 360 | 1050 | 6.5 | 3.0 | 52 | 680 | 1430 | 560 | 550 | 530 |
| SC(B)11-100/35 | 650 | 1990 | 6.5 | 1.8 | 56 | 890 | 1510 | 760 | 660 | 550 |
| SC(B)11-400/35 | 1520 | 4960 | 6.5 | 1.6 | 62 | 1840 | 1770 | 960 | 820 | 570 |
| SC(B)11-1000/35 | 2690 | 9660 | 6.5 | 1.0 | 66 | 3990 | 1980 | 960 | 820 | 590 |
| SC(B)11-2000/35 | 4220 | 16730 | 6.5 | 0.7 | 69 | 6410 | 2390 | 1220 | 1070 | 655 |
A: They are fire-resistant, pollution-free, and safe for load center installation. They offer low energy loss, low noise, and require zero maintenance.
A: Yes, the resin-insulated design provides excellent moisture resistance, making them ideal for harsh and humid conditions.
A: Yes, it features an intelligent signal temperature control system that monitors all three phases and manages fan operation automatically.
A: Forced air cooling allows the transformer to operate at an increased capacity beyond its base rating while maintaining thermal stability.
A: Yes, they are designed to be pollution-free and use fire-resistant materials, ensuring safety for both the facility and the environment.
A: They comply with international and national standards including GB6450, GB/T10228, and JB/T10088 for safety, quality, and performance.
